| Rubber Material | Natural rubber |
|---|---|
| Ø Unloaded [mm] | 34 |
| Ø loaded [mm] | 38 |
| Minimum curve radius [mm] | 20 |
| Maximum stroke [mm] | 5 |
| Volume [cm³] | 3,7 |
| Weight [g] | 4 |
| Force at -0,4 bar [Kgf] | 3,39 |
| Force at -0,6 bar [Kgf] | 4,64 |
| Force at -0,8 bar [Kgf] | 5,69 |
| Force at -0,9 bar [Kgf] | 6,25 |
| Suitable for | Flat surfaces, Deformable materials, Horizontal handling |
Download datasheet (.pdf)
Download CAD3D file (.stp)
