| Rubber Material | Nitrile |
|---|---|
| Ø Unloaded [mm] | 25 |
| Ø loaded [mm] | 26 |
| Minimum curve radius [mm] | 7 |
| Maximum stroke [mm] | 10 |
| Volume [cm³] | 3,8 |
| Number of folds | 2,5 |
| Force at -0,4 bar [Kgf] | 1,03 |
| Force at -0,6 bar [Kgf] | 1,75 |
| Force at -0,8 bar [Kgf] | 2,27 |
| Force at -0,9 bar [Kgf] | 2,29 |
| Suitable for | Flat surfaces, Curved surfaces |
| Advantages | Wide range of diameters, Versatility, Height compensation |
Download datasheet (.pdf)
