| Rubber Material | Natural rubber |
|---|---|
| Ø Unloaded [mm] | 60 |
| Ø loaded [mm] | 60,5 |
| Minimum curve radius [mm] | 20 |
| Maximum stroke [mm] | 28 |
| Volume [cm³] | 85 |
| Number of folds | 5,5 |
| Force at -0,4 bar [Kgf] | 6,06 |
| Force at -0,6 bar [Kgf] | 6,81 |
| Force at -0,8 bar [Kgf] | 6,85 |
| Force at -0,9 bar [Kgf] | 7,73 |
| Suitable for | Flat surfaces, Spherical surfaces, Curved surfaces, Horizontal handling, Food |
| Advantages | Lifting stroke, Great adaptability |
Download datasheet (.pdf)
